360 Slim Dual Nand Only Loading Xell After 13604 XBL Update...

[livinglegend187]

Hello....

Well i Have One Hell of a Weird issue With My Dual Nand RGH 360 Slim Console.For Some Reason i Can only Boot Xell on My 2nd Nand it Will Not Load FB or GBoot..

My Slim Was at originally Dash 13599 When i Did the RGH Mod and Both Nands Were Working Just Fine one For Live and one For RGH...
Here,s Where all My Problems Start I Connected To Live Using My Stock Nand and Updated To 13604...[[FIRST TIME]] That was Today
I Then Powered Down and Switched Nands to the RGH and Was going To Re-do My Skins For The New FSD2.2 Now For Some Reason Can not Boot To a Hacked Dash Just Xell Will Work...

I Can Still Read/Write To Both Nands Without any errors and Play The N64 Emulator Using Xell on the 2nd Nand.

I Have Re-flashed 2 Freeboot IMG,S That Were Working Fine Before The Update and Still Not Working.....
and also Remade Images Over 10 Times Now........

So Basically My Console Still Loads The Stock XBL Nand Fine But The 2nd Nand Will only Load Xell..??[[NO DASH]]

When Trying To Load a Hacked Dash The Console Will Just Sit there With the Middle Green Light on For Ever if i Let it....
But if i Boot With Eject it will load Xell With-in 10 Seconds Every time..........

What Do U Guys Think The Issue Would Be.

P.S I Usually Never Need to Ask Questions... i Usually Find The Answer But I Just Don,t Know on this One


Here is a Picture of My Solder Job.....

[ddxcb]

Hello....

Well i Have One Hell of a Weird issue With My Dual Nand RGH 360 Slim Console.For Some Reason i Can only Boot Xell on My 2nd Nand it Will Not Load FB or GBoot..

My Slim Was at originally Dash 13599 When i Did the RGH Mod and Both Nands Were Working Just Fine one For Live and one For RGH...
Here,s Where all My Problems Start I Connected To Live Using My Stock Nand and Updated To 13604...[[FIRST TIME]] That was Today
I Then Powered Down and Switched Nands to the RGH and Was going To Re-do My Skins For The New FSD2.2 Now For Some Reason Can not Boot To a Hacked Dash Just Xell Will Work...

I Can Still Read/Write To Both Nands Without any errors and Play The N64 Emulator Using Xell on the 2nd Nand.

I Have Re-flashed 2 Freeboot IMG,S That Were Working Fine Before The Update and Still Not Working.....
and also Remade Images Over 10 Times Now........

So Basically My Console Still Loads The Stock XBL Nand Fine But The 2nd Nand Will only Load Xell..??[[NO DASH]]

When Trying To Load a Hacked Dash The Console Will Just Sit there With the Middle Green Light on For Ever if i Let it....
But if i Boot With Eject it will load Xell With-in 10 Seconds Every time..........

What Do U Guys Think The Issue Would Be.

P.S I Usually Never Need to Ask Questions... i Usually Find The Answer But I Just Don,t Know on this One


Here is a Picture of My Solder Job.....

on the RGH image, change the LDV value up by 1.

[livinglegend187]

Worked Perfect Changed LDV From 5 To 6

You Sir are a Master I Owe u one.......


Thank you.

[ddxcb]

Worked Perfect Changed LDV From 5 To 6

You Sir are a Master I Owe u one.......


Thank you.

keep in mind, fuses are not emulated with RGH, and if you dont know the LDV, check xell on fuseline seven.

and also be another dash update soon xD

[livinglegend187]

Thank you For The info...

[iLLNESS]

when building a ggbuild/etc image on a dual nand, id suggest to always read the original updated nand and use that as source. wont have issues with ldv or anything this way

[raidenxtribe]

FACT: if you upgrade  original nand freeboot won't boot anymore (LDV +1) but xellous will boot (no LDV check), so you can start Xellous with network plugged in, use http connection to get the RAW FLASH after switching NANDs on the FLY, if you are desperate to get original upgraded nand, it will work, I tested it 2 times just to be sure...

the downside is 1 F**king hour to wait O_O

Some images:

[barnhilltrckn]

FACT: if you upgrade  original nand freeboot won't boot anymore (LDV +1) but xellous will boot (no LDV check), so you can start Xellous with network plugged in, use http connection to get the RAW FLASH after switching NANDs on the FLY, if you are desperate to get original upgraded nand, it will work, I tested it 2 times just to be sure...

the downside is 1 F**king hour to wait O_O

Some images:

Wow ive never heard of it taking that long through xell. I can download mine in around a min or so. Something is wrong there for it to be taking that long.

[Pacote-san]

FACT: if you upgrade  original nand freeboot won't boot anymore (LDV +1) but xellous will boot (no LDV check), so you can start Xellous with network plugged in, use http connection to get the RAW FLASH after switching NANDs on the FLY, if you are desperate to get original upgraded nand, it will work, I tested it 2 times just to be sure...

the downside is 1 F**king hour to wait O_O

Some images:

1 hour? i can download a full 512mb in 5 min with http xell...i always stop the download when it passes the 70mb cause you dont need more then 64mb but either way,,,

[raidenxtribe]

I don't know why XD my LAN is perfectly working, maybe it's caused by the NAND hot swap ?

[iLLNESS]

i havent tested it quite yet, but new dash requires LDV increase (rolled out last night) if you want to dual boot 13604 with latest dash that came out (same issue as OP)

or as i mentioned, you can just dump the new dash nand after last nights update and rebuild with rgbuild to fix.

again,i havent confirmed as i didn't have time this morning but i was also only able to boot to xell and retail dash, not my ggbuild dash i built when 13604 came out.
